Fanvil PA2-KIT Accessory Package
The Fanvil PA2-KIT is an official accessory package for the Fanvil PA2 SIP Intercom/Paging Gateway, providing the core audio, video, microphone, and call-button components needed to build a customized SIP intercom or paging endpoint. The kit combines a 720p IP camera module, 5W/8Ω speaker module, high-sensitivity microphone module, and illuminated stainless-steel button module.
Designed to simplify custom PA2 installations, the PA2-KIT uses matched plug-and-play components rather than requiring installers to source and test individual speakers, microphones, cameras, and buttons. Waterproof and dust-resistant component designs, adjustable camera positioning, shielded wiring, and a rugged IP67/IK10 button make the kit well suited for custom intercom panels, door-entry stations, paging endpoints, kiosks, and other PA2-based communication projects.
Key Features
- Complete PA2 Accessory Set: Includes the camera, speaker, microphone, and button modules required for building a customized PA2 audio/video intercom endpoint.
- 720p HD Camera: IP camera module supports 1280 × 720 main-stream video and adjustable installation angle for flexible positioning.
- 5W/8Ω Speaker: Waterproof speaker module provides higher-output audio for intercom and paging applications.
- High-Sensitivity Microphone: Microphone module provides -38 dB ± 2 dB sensitivity with waterproof and dustproof protective construction.
- Stainless-Steel Call Button: Self-restoring illuminated button provides durable call or programmed function activation.
- IP67 & IK10 Button Protection: Button module is designed for water, dust, and impact resistance in demanding installations.
- Plug-and-Play Components: Components are designed specifically for the Fanvil PA2 to reduce component-selection and matching requirements.
- Shielded Module Wiring: Speaker, microphone, and button modules include 150 cm shielded connection wiring.
- Flexible Camera Positioning: Wide-angle camera module allows the installation angle to be fine-tuned for the intended viewing area.
- Custom Intercom Design: Individual modules can be integrated into a custom enclosure or front panel while the PA2 provides the SIP, network, audio, and control functionality.
Applications & Use Cases
- Custom SIP Intercoms: Provides matched audio, video, microphone, and button components for building a customized PA2-based intercom endpoint.
- Door Entry Stations: Camera, microphone, speaker, and illuminated button can be incorporated into custom entrance and visitor-communication panels.
- Paging Endpoints: Speaker and microphone components support two-way communication and paging applications using the Fanvil PA2.
- Industrial Enclosures: Compact modules can be installed into custom panels and housings for specialized commercial or industrial environments.
- Kiosks & Help Points: Supports building assistance, call-for-help, and visitor communication stations around a PA2 gateway.
- System Integrator Projects: Reduces the need for installers to independently select and test PA2-compatible audio/video components.
Technical Specifications
IP Camera Module
- Maximum Main Stream: 1280 × 720
- Sub-Stream: 704 × 576
- Video Codec: H.264
- Video Streaming: Dual-stream support
- Image Sensor: 1/4-inch H62 CMOS
- Color Sensitivity: 0.1 lux at F1.2
- Black & White Sensitivity: 0.01 lux at F1.2
- Lens: Wide-angle lens
- Camera Adjustment: Mounting angle can be fine-tuned
- Power: Supplied by the Fanvil PA2 LAN camera port at 12V DC
- Installation: Self-adhesive module design
Speaker Module
- Speaker Rating: 5W / 8Ω
- Speaker Diameter: 57 mm
- Speaker Height: 13.7 mm
- Protection: Waterproof and dustproof protective-film design
- Installation: Self-adhesive mounting layer
- Cable: 150 cm shielded wire
Microphone Module
- Sensitivity: -38 dB ± 2 dB
- Standard Working Voltage: 3V
- Maximum Working Voltage: 10V
- Output Impedance: ≤2.2 kΩ
- Microphone Diameter: 9.7 mm
- Microphone Height: 4.7 mm
- Protection: Waterproof and dustproof protective-film design
- Installation: Self-adhesive mounting layer
- Cable: 150 cm shielded wire
Button Module
- Construction: Stainless steel
- Button Type: Self-restoring illuminated push button
- Protection Rating: IP67
- Impact Rating: IK10
- Mechanical Life: 200,000 activations
- LED Life: 400,000 hours
- Button Diameter: 16 mm
- Button Height: 23.8 mm
- Cable: 150 cm shielded wire
Package Includes
- IP Camera Module: 1 × Fanvil PA2-KIT 720p camera module
- Speaker Module: 1 × 5W / 8Ω speaker module
- Microphone Module: 1 × high-sensitivity microphone module
- Button Module: 1 × illuminated stainless-steel button module
Compatibility & Buying Information
- Required PA2 Gateway: The PA2-KIT is an accessory package for the Fanvil PA2 SIP Intercom/Paging Gateway. The PA2 gateway itself is not included.
- Camera Connection: The camera must connect to the dedicated LAN/camera connection on the Fanvil PA2, which supplies 12V DC to the module.
- Important PoE Warning: Do not connect the PA2-KIT camera module directly to a PoE injector or PoE switch; Fanvil warns that doing so can damage the camera.
- Custom Installation: The kit provides the internal camera, speaker, microphone, and button components rather than a finished weatherproof intercom enclosure. The installer is responsible for the final panel or enclosure design.
- PA2 Integration: SIP registration, paging, intercom, networking, power, relay control, and other system functions are provided by the separately purchased Fanvil PA2.
- Component Protection: Individual modules include waterproof/dustproof design features, but the environmental rating of the completed intercom depends on the final enclosure and installation.
Manufacturer
FANVIL
Warranty
24 MONTH
UPC
889837000939
Condition
NEW
